Sensing Classification
Electromagnetic sensors of this type utilize a single active coil to measure absolute changes in the electrical and magnetic properties of a test material. An absolute probe operates by comparing the impedance of its single coil against a reference value, making it highly sensitive to slow-moving or gradual variations such as material thickness or temperature drift. This configuration is widely used for conductivity measurement.
Measurement Mechanism
Excitation current passes through the sensor to establish an alternating magnetic field that induces eddy currents in the adjacent specimen. When the absolute probe moves over a region of varying material properties, the total impedance of the system shifts. This change is processed through a bridge circuit where it is contrasted with a fixed internal reference.
The signal response is directly related to the absolute value of the local conductivity or permeability. Because there is only one test coil, any change in temperature or coupling is registered directly as a signal shift.
Influence Factor
Environmental factors and physical lift-off present challenges during field deployment. Temperature changes during inspection can cause baseline drift, which requires frequent nulling or compensation. Probe tilt and surface roughness can also distort the signal.
To minimize these effects, operators use spring-loaded fixtures and reference specimens maintained at the same temperature.
Calibration Requirement
Verification against traceable reference blocks remains necessary before starting any inspection. This verification establishes the operational envelope. Calibration is verified at the start and end of each inspection run.
