Board Strain
Mechanical Deformation
Physical displacement of a printed circuit substrate relative to its original dimensions occurs under thermal or mechanical loading. This measurement of board strain identifies the risk to solder joints and surface mount components during assembly or operation. The value is typically expressed in microstrain to capture the minute changes that threaten ceramic capacitors and ball grid array connections.
Stress Threshold
Maximum allowable limits are dictated by the IPC-9704A standard to prevent pad cratering or component cracking. When board strain exceeds 500 to 1000 microstrain, the brittle nature of lead-free solder often leads to latent failures. Measurement occurs via stacked rosette strain gauges bonded to the assembly.
Verification Procedure
Assessment of the assembly environment involves placing sensors near high-mass components or stiffeners during the reflow and cooling phases. In-circuit testing and finishing operations provide the most common opportunities for damaging levels of board strain to accumulate. Engineers monitor these levels during the qualifying of new production lines or fixtures.
Strain rates also factor into the evaluation because rapid bending causes more damage than gradual flexure. Specialized data loggers capture these transients at kilohertz frequencies to ensure no peak goes unrecorded.
Error Source
Thermal drift within the gauge itself can introduce inaccuracies during high temperature testing. Proper compensation requires a dummy gauge on an unstressed coupon of the same material. Failure to account for the temperature coefficient of the substrate results in false readings.
This necessitates precise calibration against known temperature profiles.
