Signal Distortion
High-frequency electromagnetic emissions generated by the rapid transition times of gallium nitride and silicon carbide power transistors pose major challenges for electromagnetic compatibility. This high-frequency disturbance, known as wide bandgap switching noise, arises from the high dV/dt and dI/dt rates typical of these advanced semiconductor materials. It can propagate through both conducted and radiated pathways to corrupt nearby analog control signals.
Coupling Channel
Parasitic inductances in the circuit board traces resonate with device capacitances to form high-Q tank circuits. These resonances are excited by the fast switching edges, producing high-voltage ringing in the tens of megahertz. The resulting emissions couple into the low-voltage sensor lines via mutual inductance or capacitive crosstalk.
This coupling is exacerbated by compact system layouts.
System Consequence
Unfiltered switching noise can cause false triggering of gate drivers and error flags in communication interfaces. This corruption forces the control loop to execute safety shutdowns or operate with reduced efficiency. Over time, the continuous high-frequency stress degrades the gate oxides of the power devices, leading to premature failure of the inverter.
Shielding and separation of signal and power grounds are required to protect the integrity of the measurement signals.
Mitigation Design
Low-inductance board routing and local decoupling capacitors minimize the loop area of the high-current paths. Active gate drivers can dynamically adjust the drive current to soften the turn-on transitions without excessively increasing switching losses. These layout optimizations reduce the noise generation at its source.
