Current Distribution
A physical phenomenon causes alternating electric current to distribute non-uniformly within a conductor, with the current density being highest near the surface. In high-frequency systems, the skin effect reduces the effective cross-sectional area available for current flow, which raises the electrical resistance of the wire. This non-uniform distribution arises from circulating eddy currents induced by the changing magnetic field within the conductor.
As the operating frequency increases, the current is forced closer to the outer boundary of the wire.
Depth Calculation
Skin depth is the distance into the conductor where the current density drops to approximately thirty-seven percent of its value at the surface. This value depends inversely on the square root of the frequency and the material’s conductivity and magnetic permeability.
Resistance Rise
Conductor losses increase significantly at higher frequencies because of this reduced conductive area. For copper, the skin depth is only about 6.6 micrometres at one megahertz, meaning that current is restricted to a thin outer layer. This leads to higher thermal dissipation in power distribution networks and high-speed signal lines.
Mitigation Technique
Designers use stranded conductors, such as litz wire, to counter the rise in resistance at high frequencies. Litz wire utilizes individually insulated strands woven in a specific pattern, ensuring that each strand shares the current equally. In other applications, silver plating is applied to the surface of copper conductors to provide a lower-resistivity path for the high-frequency current.
